3 in 1 Wireless Pocket Ultrasound
C10
C10 integrates linear array, convex probe and cardiac probe into one, also built-in independent Wi-Fi, which can meet the needs of ultrasound scanning in different scenarios.
Clearer Viewing Anytime, Anywhere
Viatom transforms traditional, cart-based ultrasound into a portable, mobile phone-sized scanning device that can obtain high-quality images even in the face of challenging cases. C10 Wireless Pocket Ultrasound can transmit Wi-Fi signal by itself, realize real-time transmission of images without delay and freeze, no need to rely on the external network environment.
Comparable to Large Benchtop Ultrasound
In order to ensure the wireless imaging quality and speed, C10 replaces the fragile piezoelectric crystals used in traditional systems with an electronic linear array, and also uses 32-bit physical channels to receive signals. Viatom also adopts 128 probe array elements which are only used in large ultrasound equipment to improve the image resolution.
Multimodal Imaging
C10 has five imaging modes, B MODE, M MODE, Color MODE, PW MODE, PDI MODE. Ultra-wide frequency 2.5/3.5/5/7.5/10Mhz, scanning depth covers 20-305mm. The software operation interface of C10 is clear, and image parameters can be adjusted through multi-touch interface. Such as depth (20-308mm), gain (0-100), dynamic range (40-110, step size of 5), focal position (0-3), RPF(1.25K-4K), wall filter (0-15), etc.
Experience Infinite Scenes of Pocket Ultrasound
As a supplement to large ultrasound equipment, C10 also can improve the accessibility of medical services, not limited to the imaging department of hospitals, but can be applied to clinical diagnosis, primary medical institutions, emergency care and other practices.
Compared with traditional large-scale ultrasound, our wireless pocket ultrasound solves the problems of the traditional color ultrasound, which are limited in clinical scenarios, not easy to carry, inconvenient to use due to dragging wires, and the aseptic operation of ultrasound intervention.
Physicians can use our wireless pocket ultrasound to break through the physical space interval, shorten the first aid time for critical patients, improve the treatment effect, so that patients can enjoy safer, high-quality and efficient medical services.
Specification
Device Dimensions (main unit)
157*70*30mm
Device Weight
220-250G
Probe
3-in 1 Rrobe (Linear/Convex/Cardiac)
Convex Head
3.5/5Mhz (Depth: 90~305mm)
Linear Head
7.5/10Mhz (Depth: 20~80mm)
Cardiac
2.5/5Mhz (Depth: 90~160mm)
Probe Element
128
Clinical Applications
Abeomen/
Gynecology/
Obstetric/
Cardiac/ Urology/
Kindney/
Thyroid/
Pediatrics/
Vascular/ MSK/
Breast/Carotid/
Small Parts
Clinical Applications
Abeomen/
Gynecology/
Obstetric/
Cardiac/
Urology/
Kindney/
Thyroid/
Pediatrics/
Vascular/ MSK/ Breast/Carotid/
Small Parts
Radius
R45
Image Adjust
BGain, TGC, DYN, Focus, Depth, Harmonic, Denios
Length
R45
